Yamaha PSR E463 Deluxe Bundle, Keyboard, Stool, Stand ,Headphones, Bag

Dimensions

Width

946 mm (37-1/4")

Height

139 mm (5-1/2")

Depth

404 mm (15-15/16”)

Weight

6.6 kg (14 lb, 9 oz) not including batteries

Keyboard & Controls

Number of Keys

61

Touch Response Settings

Soft, Medium, Hard, Fixed

Pitch Bend

Yes

Control Knobs

Yes

Display

Technology Type

LCD (Liquid Crystal Display)

Language

English

Built-In Sounds

Tone Generating Technology

AWM Stereo Sampling

Number of Polyphony (Max.)

48

Number of Voices

758 (237 Panel Voices + 24 Drum/SFX kits + 40 Arpeggio + 457 XGlite voices)

Featured Voices

8 Sweet! Voices, 3 Cool! Voices, 3 Dynamic Voices

GM Compatible?

Yes

XGLite Compatible?

Yes

Digital Effects

DSP

10 types (assignable on control knobs)

Reverb

12 types

Chorus

5 types

Master EQ

6 types

Harmony

26 types

Functions

Dual/Layers

Yes

Split

Yes

Arpeggio

150 types

Melody Suppressor

Yes

Crossfade

Yes (for Internal/AUX IN)

Backing Accompaniment Styles

Number of Preset Styles

235

Fingering

Multi finger

Style Control

ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL, TRACK ON/OFF

File Format

Style File Format (SFF)

One Touch Setting (OTS)

Yes

Expansion Style

10

Groove Creator

Number of Grooves

35

Number of Sections

5 (4 Sections + 1 Musical Climax/Ending)

Songs

Number of Preset Songs

30

Number of Recording Song Spaces

10

Number of Recording Tracks Per Song

6 (5 Melody + 1 Style/Groove Creator)

Total Data Capacity

Approx. 19,000 notes (when only “melody” tracks are recorded)

MIDI File Playback Format

SMF (Formats 0 & 1)

MIDI File Recording Format

Original File Format (SMF 0 conversion function)

USB Audio Recorder

Recording Time (max.)

80 minutes (approx. 0.9 GB) per Song

Playback & Recording Audio Specification

WAV (44.1 kHz, 16 bit, stereo)

Quick Sampling

Sampling Types

Normal, Oneshot, Loop

Samples (Preset/Usesr)

5

Sampling Time

Approx. 9.6 sec

Sampling Sources

AUX IN

Sampling Format

Original File Format (16 bit, stereo)

Sampling Rate

44.1 kHz

Registration System

Number of Buttons

4 (x 8 banks)

Lesson/Guide

Yamaha Education Suite (Y.E.S.)

Lesson 1 – 3 (Listening, Timing, Waiting), Repeat & Learn, Chord Dictionary

Overall Controls

Metronome

Yes

Tempo Range

11 – 280

Transpose

-12 to 0, 0 to +12

Tuning

427.0 – 440.0 – 453.0 Hz (approx. 0.2 Hz increments)

Scale Settings

Yes

Storage and Connectivity

Internal Memory

Approx. 1.73 MB

External Drive Compatibility

USB flash drive

Power Source

DC IN 12 V

AUX IN Connection

Stereo-Minijack

Headphones

x 1 (PHONES/ OUTPUT)

Sustain Pedal Connection

Yes

USB-To-Device Port

Yes (USB-A Socket)

USB-To-Host Port

Yes (USB-B Socket): Transfers MIDI and Audio (44.1 kHz, 16 bit stereo) in realtime to iOS, Mac and Windows (drivers may be required). Cables required.

Amplification

Onboard Amplifiers

6 W + 6 W (When using PA-150 AC adaptor)

Speakers

12 cm x 2

Power Supply

Power Source

Yamaha PA150 (Included) or a recommended equivalent; alternatively Six ‘AA’ size alkaline (LR6), manganese (R6) or Ni-MH rechargeable (HR6) batteries

Power Consumption

8 W (When using PA-150 AC adaptor)

Auto Power Off Function

Yes

Included Accessories

Music Rest

Yes

Song Book

Download from website

Mains Power Adapter

Yes (Yamaha PA150)
