macOS®
macOS version 10.13 or later
200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates)
Available USB port
Windows®
Windows 10 or later (64-Bit Only)
200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates and low-latency ASIO support)
Available USB port
Chrome OS
For information on compatibility with Chrome OS, click here.

iOS/iPadOS
For information on compatibility with iOS/iPadOS, click here.
Android
For information on compatibility with Android devices, click here.

The above are the hardware system requirements for this product.
DAW software and Operating System requirements vary.

Click here for Studio One’s system requirements.
VST Compatible Logo ASIO Compatible Logo

VST is a registered trademark of Steinberg Media Technologies GmbH
ASIO is a trademark and software of Steinberg Media Technologies GmbH
All other trademarks are property of their respective holders
Technical Specifications
Mi​crophone
Type Mono Condenser
Polar Pattern Cardioid, Bidirectional (Figure 8), Omnidirectional
Frequency Response (±3.0 dB) 20 Hz to 20 kHz
Sensitivity 1 mV/Pa
Max SPL 110 dB <3% THD
Headphone Output
Type 1/8" TRS active stereo
Power Output (RMS) 22.6 mW (16Ω)
THD 0.008%
Frequency Response 20 Hz to 20 kHz
Impedance 16Ω
Dynamic Range 77.5 dB
Audio Interface
Type USB-C® compatible USB 2.0
Sample Rate 44.1, 48, 88.2, and 96 kHz (​Note: 44.1 and 48 kHz only on macOS while in Multi Mode)
Bit Depth 24-bit
Power USB Bus Power
Hardware Controls Direct Monitor, Mic Gain, Headphone Level, Mute, Preset Select
Software Controls Mic Gain, Pattern Select, Monitor Mix, Preset Management
Onboard DSP
PreSonus Fat Channel: High Pass Filter, Noise Gate, 3 Compressor models, 3 EQ models, and Limiter

Voice Effects: Comb Filter, Delay, Doubler, Ring Modulator, Vocoder

Reverb

Physical
Dimensions (HxWxD) 8.875" x 5.125" x 5.125" (225 x 130 x 130 mm)
Weight 1.6 lbs. (0.73 kg)
