Boss WL-20 | Plug and Play Wireless instrument system
€198.00
Once you experience the easy wireless independence provided by the WL-20 series, youll never go back to using a standard cable again!
2 in stock
Once you experience the easy wireless independence provided by the WL-20 series, youll never go back to using a standard cable again!
- SPECIFICATIONS (RECEIVER)
- Wireless Format
- BOSS proprietary digital audio format
- Wireless carrier frequency
- 2.4 GHz
- Compatible Channels
-
14
(May vary due to local conditions) - Transmission Range
-
50 feet line-of-sight
(May vary due to local conditions) - Latency
- 2.3 ms
- Dynamic Range
- 110 dB or greater
- Frequency Response
- 20 Hz--20 kHz
- Nominal Output Level
- -10 dBu
- Output Impedance
- 1 k ohm
- Recommended Load Impedance
- 10 k ohms or greater
- Indicators
-
POWER
RECEIVE - Connectors
-
Output plug: 1/4-inch TRS phone type
TRANSMITTER jack: 1/4-inch TRS phone type
DC IN 5 V port: USB Micro-B type - Power Supply
-
Rechargeable lithium-ion battery
Supplied from the DC IN 5 V port - Current Draw
-
During wireless operation: 60 mA
While charging: 500mA - Battery charging time
-
Charging only the receiver: Approximately 3 hours
Charging simultaneously with the transmitter: Approximately 4 hours - Expected battery life under continuous use
-
Approximately 7 hours
* These figures will vary depending on the actual conditions of use. - Accessories
-
Owner's Manual
Leaflet USING THE UNIT SAFELY
Transmitter
Micro USB cable for charging (*1)
*1: Use a standard USB AC adaptor (5 V/over 0.5 A) for charging. - SIZE AND WEIGHT(RECEIVER)
- Width
-
87 mm
3-7/16 inches - Depth
-
25 mm
1 inches - Height
-
38 mm
1-1/2 inches - Weight
-
60 g
3 oz - SPECIFICATIONS (TRANSMITTER (WL-T))
- Nominal Input Level
- -10 dBu (1 M ohm)
- Indicator
- BATTERY
- Connectors
-
Input plug: 1/4-inch TRS phone type
DC IN 5 V port: USB Micro-B type - Power Supply
-
Rechargeable lithium-ion battery
Supplied from the DC IN 5 V port - Current Draw
- 350mA
- Battery charging time
- Approximately 3 hours
- Expected battery life under continuous use
-
Approximately 12 hours
* These figures will vary depending on the actual conditions of use. - SIZE AND WEIGHT (TRANSMITTER (WL-T))
- Width
-
87 mm
3-7/16 inches - Depth
-
22 mm
7/8 inches - Height
-
36 mm
1-7/16 inches - Weight
-
43 g
2 oz - * 0 dBu = 0.775 Vrms
- *The specifications are subject to change without notice.
