BOSS VE-22 VOCAL FX | Portable Multi FX Voice Toolbox

SPECIFICATIONS



Sample Rate

48 kHz

AD Conversion

24 bits + AF method
AF method (Adaptive Focus method) is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.

DA Conversion

32 bits

Processing

32-bit floating point

Effects

39 types

Memories

99 (User) + 50 (Preset)

Phrase Loop

37 sec.

Nominal Input Level

INPUT: -40 dBu (Adjustable)
AUX IN: -20 dBu

Maximum Input Level

INPUT: 0 dBu
AUX IN: 0 dBu

Input Impedance

INPUT: 4 k ohms
AUX IN: 27 k ohms

Nominal Output Level

OUTPUT L/MONO, R: -40 dBu
PHONES/LINE OUT: -10 dBu

Output Impedance

OUTPUT L/MONO, R: 600 ohms
PHONES/LINE OUT: 47 ohms

Recommended Load Impedance

OUTPUT L/MONO, R: 600 ohms or greater
PHONES/LINE OUT: 47 ohms or greater

Display

Graphic color LCD 320 x 240 dots

Controls

HARMONY switch
DOWN switch
UP switch
MENU button
EXIT button
PHONES/LINE knob
MEMORY knob
HARMONY knob
EFFECT knob
ECHO knob
MIC SENS knob
PHANTOM switch
POWER switch

Connectors

INPUT connector: XLR type, balanced, phantom power (DC 48 V, 10 mA Max)
OUTPUT L/MONO, R connectors: XLR type
PHONES/LINE OUT jack: Stereo miniature phone type
AUX IN jack: Stereo miniature phone type
CTL1,2 / EXP jack: 1/4-inch TRS phone type
USB COMPUTER port: USB Type-C(R)
DC IN jack

Power Supply

Alkaline battery (AA, LR6) x 4
or
AC adaptor (PSA-S series: sold separately)

Current Draw

260 mA (with phantom power)
180 mA (without phantom power)

Expected battery life under continuous use

Alkaline battery: Approximately 6 hours (with phantom power)
Alkaline battery: Approximately 9 hours (without phantom power)
* This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.

Accessories

STARTUP GUIDE
Alkaline battery (AA, LR6) x 4
Leaflet “USING THE UNIT SAFELY”

Options (sold separately)

AC adaptor: PSA-S series
Footswitch: FS-5U, FS-6, FS-7
Expression Pedal: EV-30, FV-500L, FV-500H, Roland EV-5
Carrying Bag: CB-VE22

SIZE AND WEIGHT

Width

218 mm
8-5/8 inches

Depth

143 mm
5-11/16 inches

Height

64 mm
2-9/16 inches

Weight (including battery)

910 g
2 lb 0.1 0z

* 0 dBu = 0.775 Vrms

*The specifications are subject to change without notice.
