Boss Katana:GO | Personal Headphone Guitar Amplifier

Sample Rate

48 kHz

AD Conversion

32 bits + AF method
AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.

DA Conversion

32 bits

Memories

Guitar mode: 30
Bass mode: 30

Nominal Input Level

INPUT: -10 dBu

Input Impedance

INPUT: 1 M ohm

Maximum Output Level

PHONES: 30 mW + 30 mW

Output Impedance

PHONES: 4.7 ohms

Recommended Load Impedance

PHONES: 16 ohms or greater

Display

Graphic OLED display (128 x 32 dots)

Controls

Master volume knob
POWER switch
A button
B button
C button
Bluetooth(R) button
STAGE FEEL button
Multi-function button

Connectors

Input plug: 1/4-inch phone type
PHONES jack: Stereo miniature phone type
USB port: USB Type-C(R)

Bluetooth

Profile Support: A2DP (Audio)
GATT (MIDI over Bluetooth Low Energy)

Power Supply

Rechargeable lithium-ion battery
Supplied from the USB port

Current Draw

500 mA

Expected battery life under continuous use

Approximately 5 hours
* These figures will vary depending on the actual conditions of use.

Battery charging time

Approximately 3 hours
* To charge the unit, use the USB port of a computer or a commercially available USB power supply adaptor (5 V, 500 mA or higher).

Accessories

Leaflet “Quick Start“
Leaflet “USING THE UNIT SAFELY“
USB Type-C(R) to USB Type-A cable

SIZE AND WEIGHT (INCLUDE HANDLE AND RUBBER FEETS)

Width

45 mm
1-13/16 inches

Depth

125 mm
4-15/16 inches

Height

24 mm
1 inches

Weight

70 g
3 oz

* 0 dBu = 0.775 Vrms
