- Rated Power Output
10 W (5 W + 5 W)
- Nominal Input Level
GUITAR/STEREO IN L, R: -10 dBu (1 M ohm)
i-CUBE LINK/AUX IN: -20 dBu (15 k ohm)
- Nominal Output Level
LINE OUT L/MONO, R: -10 dBu
- Speakers
10 cm (4 inches) x 2
- Controls
POWER switch
AMP TYPE knob (ACOUSTIC SIM, JC CLEAN, US COMBO, BRIT COMBO, HI-GAIN STACK, METAL STACK, EXTREME, MIC, STEREO IN)
MEMORY button
GAIN knob
VOLUME knob
BASS knob
MIDDLE knob
TREBLE knob
EFFECTS knob (CHORUS, FLANGER, PHASER, TREMOLO, HEAVY OCTAVE)
DELAY/REVERB knob (DELAY, REVERB, SPRING)
TAP button
MIC VOL knob
MASTER knob
LOOPBACK switch (i-CUBE LINK/AUX IN)
LOOPBACK switch (USB)
- Indicators
POWER
MEMORY
TAP
REC
PLAY
DUB
- Connectors
GUITAR jack/STEREO IN L, R jacks: 1/4-inch phone type
PHONES/REC OUT jack: Stereo Miniature phone type (Stereo, CTIA)
i-CUBE LINK/AUX IN jack: Stereo Miniature phone type (Stereo, CTIA)
LINE OUT L/MONO, R jacks: 1/4-inch phone type
FOOT SW jack: 1/4-inch TRS phone type
Bluetooth ADAPTOR connector: Dedicated connector
USB port: USB B type
DC IN jack
- Power Supply
AC adaptor (DC 9 V)
Alkaline battery (AA, LR6) x 8
Rechargeable Ni-MH battery (AA, HR6) x 8
- Current Draw
360 mA
- Expected battery life under continuous use
Alkaline battery: Approximately 8 hours
Rechargeable Ni-MH battery: Approximately 10 hours (*1)
*1 When using batteries having a capacity of 2,500 mAh.
* These can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.
- Dimensions
341 (W) x 162 (D) x 215 (H) mm
13-7/16 (W) x 6-7/16 (D) x 8-1/2 (H) inches
- Weight (excluding AC adaptor)
3.3 kg
7 lbs 5 oz
- Accessories
Owner's Manual
Leaflet USING THE UNIT SAFELY
AC adaptor
Power cord
Mini cable (4-pole miniature phone type)
- Options (sold separately)
Footswitch: FS-5U, FS-6, FS-7
Bluetooth(R) Audio MIDI Dual Adaptor (MODEL BT-DUAL)
Wireless MIDI Expression Pedal: EV-1-WL
* 0 dBu = 0.775 Vrms
